VHF & UHF, 2 and 16 Channels
Radio hardware features: - 2 and 16 Position Rotary Channel Selector with Stop
- 2 Programmable Side Buttons
Operator friendly controls and features include: - Large Rotary Channel Selector
- Rotary On/OFF and Volume Control
- Accessory Connector for convenient access
- Battery Latch Lock
- Large Textured PTT
- Spring Action Belt Clip
- Rugged, Die-Cast Chassis
- 3 Programmable Option Buttons
Motorola HT1000 The HT1000 portable offers you a small, rugged, economically packaged radio with features never before offered in a Motorola HT portable product. In addition to size, durability, and affordability advantages the HT1000 radio offers, it also includes programmable function controls and radio-to-radio cloning for increased user flexibility.
The HT1000 radio is one of the loudest portables ever developed by Motorola. Improved voice intelligibility at high volumes means less distortion and fewer miscommunications. The radio’s standard noise canceling microphone will minimize background noise.
The HT1000 radio features Motorola’s broadest band range. With “Full Band VHF” a single model can operate from 136-174MHz. The entire UHF band is covered with 2 models, and the 800MHz band needs only one.
Channel scan monitoring allows the HT1000 to scan all of its operating channels. Channel scan is capable of scanning for PL, DPL, Carrier Squelch, Quick Call and Stat-Alert Selective Call, and be configured for Non-Priority or Single Priority operation. The HT1000 radio also includes Talk-back scan and nuisance channel delete and unwanted active channel from the scan list by simply pressing a button.
The HT1000 portable can be programmed to adjust RF power levels automatically on a mode slaved basis, or manually through operation of a switch. Variable RF power level provides the radio with the capability of having up to two power levels in one radio, and the capability of operating in high or low power on a per channel basis.
The HT1000 portable radio makes dedicated two-way communications faster, clearer, and easier to use. This small and lightweight radio breaks the notion that size and weight must increase as the portable grows in capability. Of course, the HT1000 radio family incorporates the quality and reliability you have come to expect from Motorola.
Motorola HT1000 Features
The HT1000 has the following features:
- Frequency flexibility offers a broad band range.
- Three Side Programmable Buttons
- Quick Disconnect Accessory Port
- Built to withstand harsh conditions in rugged environments.
- Rotary Channel Selector Knob
- Noise Canceling Microphone provide clearer audio even in noisy environments.
- Top Mounted Emergency Button
- Dual Charge High Capacity Battery
- Top-Mounted Bi-Color LED Indicator
- Programmable channel spacing in VHF and UHF lets you change bandwidths in 25 or
- 12.5 kHz systems.
- Wide range of signaling options.
- 3-Postion Programmable Toggle Switch
Motorola HT1000 Models
VHF
- H01KDC9AA1-N
HT1000 VHF (136-178 MHz) 2 Channel 1-5Watt Portable Radio - H01KDC9AA3-N
HT1000 VHF 136-178 MHz 16 Channel 1-5Watt Portable Radio
UHF
- H01RDC9AA1-N
HT1000 UHF 403-470 MHz 2 Channel 1-4Watt Portable Radio - H01RDC9AA3-N
HT1000 UHF 403-470 MHz 16 Channel 1-4Watt Portable Radio - H01SDC9AA1-N
HT1000 UHF 450-520 MHz 2 Channel 1-4Watt Portable Radio - H01SDC9AA3-N
HT1000 UHF 450-520 MHz 16 Channel 1-4Watt Portable Radio - H01UDC9AA3-N
HT1000 800 MHz (806-870 MHz) 16 Channel 1-4Watt Portable Radio
All Motorola HT1000 Models Include: Standard Battery – (VHF/UHF NiCd 1200 MAh 7.5v)
Standard 120v Single Unit Slow Rate
Standard Antenna
2.5” Belt Clip
User Guide
1 -Year Warranty
Motorola HT1000 Applications
Public Safety
Mining
Petroleum
Motorola HT1000 Accessories
Expand your radios capabilities with Motorola Original accessories. Motorola HT Series portable radio accessories can turn your radio system into a custom communication system for your business needs. Adding the proper headsets, microphones, batteries, chargers, or carry cases can enhance the productivity of the people who use two-way radios. Motorola Original accessories are built with the highest quality standards and are specifically engineered to assure maximum performance of your radio, no matter what your profession.
Batteries Motorola original b atteries with different chemistries to best suit your needs help keep your HT1000 radio fully functioning at all times, so you can rest assured they are ready whenever you need them.
NTN7143 NiCD Battery Standard Capacity 1200 mAh 7.5V
NTN7144 NiCd Battery High Capacity 1500 mAh 7.5V
NTN7146 NiCD Battery Standard Capacity (Intrinsically Safe) 1200 mAh 7.5V
NTN7147 NiCD Battery High Capacity (Intrinsically Safe) 1300 mAh 7.5V
Chargers You need a charger to keep your batteries ready whenever you need them. Choose the Motorola Original charger that best fits your need.
NTN1168 Charger Desktop Rapid Rate 110V
NTN1171 Charger Rapid 1-Hour 110V
NTN1174 Charger Single 10-Hour
NTN1177 Charger Multi Unit Rapid (Six-Pocket)110V
Audio Motorola original a udio accessories enhance your communication system. Remote speaker microphones offer the convenience of communication without having to remove the radio from your belt. Lightweight headsets provide hands- free communication so you can work and communicate simultaneously. Comfortable earpieces mute the radio speaker while channeling the audio directly to your ear, so you can monitor transmissions clearly and privately.
Remote Speaker Microphones NMN6193 Remote Speaker Microphone
NMN6191 Noise Canceling Remote Speaker Microphone
NMN6228 30" Noise-Canceling Public Safety Speaker/Microphone
NMN6243 18" Noise-Canceling Public Safety Speaker/Microphone
NMN6244 24" Noise-Canceling Public Safety Speaker/Microphone
Earpieces BDN6664 Receive Only Earpiece - Beige (requires BDN6676 adapter)
BDN6719 Ear Receiver with 3.5 mm Threaded Plug
BDN6780 Single Earbud with Microphone and PTT (requires BDN6676 adapter)
BDN6781 Single Earbud, receive only (requires BDN6676 adapter)
NMN6246 Earbud w/Boom Micr and in-line PTT (requires BDN6676 adapter)
Surveillance Accessories The following surveillance accessories require the BDN6676D (3.5 mm threaded adapter jack) that attaches to the radio, unless being used with speaker/microphone.
BDN6664 1-wire Earpiece - Beige
BDN6726 1-wire Earpiece - Black
BDN6665 1-wire Extra Loud Earpiece - Beige
BDN6727 1-wire Extra Loud Earpiece - Black
BDN6666 1-wire Earpiece w/Volume Control
BDN6728 1-wire Earpiece with volume control - Black
BDN6667 2-wire Earpiece with combined Mic/PTT -Beige
BDN6729 2-wire Earpiece with combined Mic/PTT - Black
BDN6669 2-wire Extra Loud Earpiece with combined mic/PTT - Beige
BDN6731 2-wire Extra Loud Earpiece with combined mic/PTT - Black
BDN6668 3-wire Earpiece with separate Mic/PTT - Beige
BDN6730 3-wire Earpiece with separate Mic/PTT - Black
BDN6670 3-wire Extra Loud Earpiece with separate mic/PTT - Beige
BDN6732 3-wire Extra Loud Earpiece with separate mic/PTT - Black
NTN8370 Extreme Noise Kit provides 24 dB of noise reduction
NTN8371 Low Noise Kit; includes rubber Eartip for low noise
BDN6676 3.5 mm Jack Adapter with Quick Disconnect Latch
Headsets NMN6245 Single Muff Lightweight headset (Requires BDN6676 3.5mm Adapter)
BDN6676 HT1000 Audio Access Adapter 3.5mm w/PTT
NMN1020 Lightweight Headset w/Boom Mic for Helmet (Requires BDN6676 Adapter)
NMN6258 Over the head with In-Line PTT
NMN6259 Behind the head with In-Line PTT
BDN6645 Heavy Duty Headset w/Boom Mic -24 dB (Requires BDN6673 Adapter)
BDN6635 Heavy Duty (VOX) Headset w/Boom Mic (Requires BDN6673 Adapter)
BDN6636 Heavy Duty (VOX) Headset w/Throat Mic (Requires BDN6673 Adapter)
BDN6673 Radio Adapter Cable
Ear Microphones Voiceducer BDN6708 Ear Microphone Interface Module for PTT Only
BDN6671 Ear Microphone Interface Module for PTT & VOX
BDN6641 Ear Microphone for up to 105dB - Grey
BDN6677 Ear microphone for up to 95 dB - Black
BDN6678 Ear Microphone for up to 95dB - Beige
0180358B32 Ear Microphone Earholder Black - Small
0180358B33 Ear Microphone Earholder Black - Medium
0180358B34 Ear Microphone Earholder Black - Large0180358B35 Ear Microphone Earholder Clear - Small
0180358B36 Ear Microphone Earholder Clear - Medium
0180358B37 Ear Microphone Earholder Clear - Large
0180300E25 Ear Microphone Earguard with Adjustable Loop
0180358B38 Ear Microphone Push-to-Talk Ring Switch
0180300E83 Ear Microphone Push-to-Talk Body Switch
4280369E44 Ear Microphone Belt Clip
CommPort NTN1625 CommPort Integrated System with PTT on Radio
NTN1624 CommPort Integrated System with Palm PTT (IS / FM)
NTN1663 CommPort Integrated System with Ring PTT (IS / FM)
NTN1737 CommPort Integrated System with Snap-on-Side PTT (IS / FM)
NNTN4187 CommPort System with Body PTT Button
AAHLN9717 Audio Accessory Adapter 3.5MM
Carry Accessories Motorola original c arry cases in both nylon and leather protect your radio and provide you the freedom from holding it during standby communication. Designed with comfort and convenience in mind, these cases come in a variety of sizes and styles to fit nearly any professional application.
HLN6602 Universal Chest Pack
NTN8037 Leather Carry Case with 3" Swivel (for use with high capacity battery)
NTN8038 Leather Carry Case with 3" Swivel (for use with ultra-high capacity battery)
NTN7247 Nylon Carry Case with Belt Loop
4205638V09 Spring Action Belt Clip 2.5” (Standard with Radio)
Antennas A variety of antennas available for the Motorola HT1000 radio offer you flexibility in size and calling range. As with all of our parts and accessories, these HT1000 antennas are all Motorola Original.
VHF
8505644V01 VHF (136-150.8 MHz) Helical Antenna
8505518V01 VHF (136-150.8 MHz) Wideband Helical Antenna
VHF (150.8-162 MHz) Helical Antenna 8505644V02
VHF (136-150.8 MHz) Helical Antenna 8505644V01
VHF (162-178 MHz) Helical Antenna 8505644V03
UHF
8505644V04 UHF (403-435 MHz) Helical Antenna
8505644V05 UHF (435-470 MHz) Helical Antenna
8505644V06 UHF (470-435 MHz) Helical Antenna
8505241U05 UHF (403-520 MHz) Whip Antenna
800 MHz
NAF4000 800 MHz (806-870 MHz) Dipole Antenna
8505241U06 800 MHz (806-941 MHz) Stubby Antenna
8505241U03 800 MHz (806-870 MHz) Stubby Antenna
Download
Motorola HT1000 Spec Sheet
